Mild Steel·490~550MPa High Tensile Strength Steel / Ar+CO2 Solid wire YM-22Z

Characteristics

YM-22Z is a gas metal arc welding wire to be used with Ar+CO2 shield gas. The blowholes and the spatters are few and bead is sound in one pass fillet welding of alloified molten galvannealed steel plates of 45 to 60g/m2 galvanization level. Also, it can be apllied high speed welding of more than 100cm/min. The best effect is obtained in the conbination with an inverter controlled pulsed power source.

Applications

Alloified molten galvannealed steel plates of 45 to 60g/m2 galvanization with 1 pass welding with an inverter controlled pulsed power source.

YM-22Z

Downloads

  • Not all product sizes have been certified.
  • Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
  • ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
  • ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.
