Mild Steel·490~550MPa High Tensile Strength Steel / CO2 Solid wire YM-26

Characteristics

YM-26 is a gas metal arc welding wire to be used with CO2 shield gas. The arc is stable, the spatters are few and weldability is excellent even in high welding current range. It is obtained high efficiency since the deposition rate is high and the penetration is deep.

Applications

Welding of mild steel and 490MPa high tensile strength steel for automobiles, rolling stock, machinery, air conditioners, tools light gauge steel, steel frames, bridges and ships.

YM-26
  • JIS Z 3312 YGW11
  • AWS A5.18 ER70S-G☆

Downloads

  • Not all product sizes have been certified.
  • Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
  • ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
  • ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.

For inquiries about this product, please click here.
