Mild Steel·490~550MPa High Tensile Strength Steel / CO2 Solid wire YM-28
Characteristics
YM-28 is a gas metal arc welding wire to be used with CO2 shield gas. The arc is stable, the spatters are few and the weldability is excellent even with low current under 200A. The welding of thin plates in all position. especially in vertical downward position, is easy. Also, it shows better weldability in high speed welding of thin plates with currents of less than 300A than wires of other types. Also with Ar+CO2 mixture gas, the arc is stable, the spatters are few and the bead is beautiful in a wide welding current range.
Applications
Welding of mild steel and 490MPa high tensile strength steel for automobiles, rolling stock, electric appliances, machinery, air conditioners, light gauge steel, pipes, steel frames, bridges and ships.
- JIS Z 3312 YGW12
- AWS A5.18 ER70S-G☆
Downloads
PRODUCT CATALOG
Approvals
Reference data
- Not all product sizes have been certified.
- Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
- ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
- ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.
