570~980MPa High Tensile Strength Steel / CO2 Solid wire YM-60C
Characteristics
YM-60C is a gas metal arc welding wire to be used with CO2 shield gas. The arc is stable, the spatters are few and the weldability is excellent even in high welding current range. It is obtained high efficiency welding in automatic and semi-automatic welding due to high deposition rate and deep penetration. It is also applicable to OSCON process, our manpower saving automatic welding process.
Applications
Welding of 590MPa high tensile strength steel for steel frames, bridges, pressure vessels and penstocks.
- JIS Z 3312 G59JA1UC3M1T
- AWS A5.28 ER80S-G☆
Downloads
PRODUCT CATALOG
Reference data
- Not all product sizes have been certified.
- Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
- ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
- ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.
