PRODUCTSWELDING CONSUMABLES
570~980MPa High Tensile Strength Steel / Ar+CO2 Solid wire YM-60A
Characteristics
YM-60A is a gas metal arc welding wire to be used with Ar+5 to 25%CO2 or Ar+2 to 5%O2 shield gas. It is suitable for spray arc welding with high current and vertical butt welding with low current and high heat input. The weld metal shows excellent mechanical properties and crack resistance. The weldability is satisfactory and bead appearance is beautiful when it is used for OSCON Process, our manpower saving automatic welding process.
Applications
Welding of 590MPa high tensile strength steel for steel frames, bridges, pressure vessels, storage tanks and penstocks.
- JIS Z 3312 G59JA1UM3M1T
- AWS A5.28 ER80S-G☆
Downloads
- Not all product sizes have been certified.
- Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
- ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
- ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.
