Stainless Steel / Ar+O2 Solid wire YM-309
Characteristics
YM-309 is a gas metal arc welding wire to be used with Ar+0.5 to 2%O2 shield gas. The arc is stable, the bead appearance is beautiful with outstanding edge wetting and the weldability is satisfactory. The weld metal of 24%Cr-13%Ni contains an adequate amount of ferrite and shows excellent resistance to hot cracking.
Applications
Welding of 22%Cr-12%Ni stainless steel for petroleum, chemical engineering and textile industries, 18%Cr-8%Ni stainless clad steel and dissimilar metals such as mild steel to stainless steel.
- JIS Z 3321 YS309☆
- AWS A5.9 ER309☆
Downloads
PRODUCT CATALOG
Approvals
Reference data
- Not all product sizes have been certified.
- Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
- ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
- ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.
