Mild Steel·490~550MPa High Tensile Strength Steel / Ar+CO2 Solid wire YM-TX
Characteristics
YM-TX is a gas metal arc welding wire to be used with Ar+CO2 shield gas. As the slag volume is extremely low on the welding bead, the weld parts have excellent electrodeposition coating ability. The arc is stable, the spatters are few, the weldability is satisfactory and bead shape is flat. The weld metal shows excellent toughness and can be applied to high tensile steel sheets for automotive. It is possible to short-circuit the transfer weld with a low current. It assures excellent weldability and properties of weld metal in pulsed arc welding.
Applications
Welding of mild steel and 490MPa high tensile strength steel for automobiles, rolling stock, machinery, air conditioners and light steel frames.
- JIS Z 3312 G49A2NO☆
- AWS A5.18 ER70S-G☆
Downloads
PRODUCT CATALOG
Approvals
Reference data
- Not all product sizes have been certified.
- Approvals are updated from time to time, but in case of expiration or cannot find it, please inquiry via contact us.
- ☆It means that the product meets the classification requirements but that the JIS Mark system and AWS are not authentication to the classification by third parties.
- ★It means that the product meets most of the classification requirements. However, there is for example a partial deviation in chemical composition etc.
